The TP2324 Industrial-grade Differential Pressure Type Wind Speed Sensor boasts a sleek, minimalist design and is compact and portable.The TP2324 supports both wired and wireless communication. For wired communication, it offers RS485_MODBUS and 4-20mA data output; for wireless communication, it supports WIFI_MODBUS data acquisition and LoRa/LoRaWAN automatic data upload to IoT platforms. It is equipped with an LCD screen that displays real-time wind speed, air volume and differential pressure, and allows parameter configuration via RS485, Bluetooth, Type-C port and physical buttons.
Functional Features
This product features intuitive display, user-friendly interface and simple operation. Its main functions and features are as follows:
- Real-time Monitoring & Display The device can detect real-time wind speed, air volume and differential pressure, with intuitive display via the interface.
- Flexible Communication Options In terms of communication functions, the wired mode supports the RS485-MODBUS port for real-time data acquisition; the wireless mode supports WIFI_MODBUS data acquisition and LoRa/LoRaWAN automatic data upload to IoT platforms.
- Versatile Control Interface In terms of control functions, it is furnished with a 4-20mA analog output control interface, and allows parameter modification via physical buttons, Type-C port and Bluetooth.
- High-Performance Processing It adopts a 32-bit high-speed microprocessor, delivering robust data processing capability, high measurement accuracy and excellent real-time performance.
Application Scenarios
It is mainly applicable to various industrial settings such as boilers, refrigeration systems, HVAC systems and ventilation ducts. Characterised by simple and convenient operation as well as a clear and intuitive interface, the sensor also features small size and light weight.
